Frequency Response 60 Hz — 35 kHz Sensitivity (1W@1M) 87 dB Drive Unit Complement: 1 x 140 mm (51/2″) RST mid-bass driver 1 x 25 mm (1″) C-CAM Gold Dome tweeter Nominal Impedance 8 ohms Maximum SPL 110.8 dBA Recommended Amplifier Requirements 25 — 100 W Front ported – bass reflex. HiVE II port system Power Handling (RMS) 100 W Crossover Frequency 3.0 kHz External Dimensions (Cabinet Only (H x W x D) 250 x 140 x 140 mm (913/16 x 51/2 x 51/2″) External Dimensions (Including Table Stand (H x W x D) 280 x 150 x 180 mm (11 x 57/8…
